| HARDWARE |
| PROCESSOR |
Octa-core, 4 x 2.7 GHz + 4 x 1.7 GHz
Exynos 9810 |
| RAM |
4 GB |
| CAMERA |
Optional: |
|
Front camera |
5 MP |
|
Main camera |
13 MP Autofocus |
|
Video recording resolution |
UHD 4K (3840 x 2160 Pixel) @ 30 fps |
| INTERNAL DATA MEMORY |
64 GByte
Free available memory 48.6 GByte |
| OPTIONAL DATA MEMORY |
Optional:
microSD (up to 1024 GB)
512 GB installed |
| SENSORS |
Acceleration sensor, gyroscope, proximity sensor, geomagnetic sensor, Hall sensor, RGB light sensor |
| SPEAKER |
yes |
| INDICATORS/OPERATING MEANS |
| DISPLAY |
Can be operated while wearing gloves |
|
Touchscreen technology |
Capacitive multitouch |
|
Type |
TFT, LCD |
|
Screen diagonal |
20.31 cm |
|
Aspect ratio |
16:10 |
|
Resolution |
1920 x 1200 (WUXGA) |
|
Brightness |
480 cd/m2 (nit) |
|
Colors |
16 Mio. |
| ELECTRICAL SPECIFICATIONS |
| BATTERY TYPE |
Li-Ion 18.87 WH, 3.8 V
5050 mAh (typical)
4900 mAh (rated) |
| OPERATING DURATION |
up to 11 h |
| COMMUNICATION |
| MOBILE STANDARD |
Optional: |
|
2G |
GSM 850 MHz, GSM 900 MHz, DCS 1800 MHz, PCS 1900 MHz |
|
3G |
UMTS band: B1 (2100), B2 (1900), B4 (AWS), B5 (850), B8 (900) |
|
4G |
LTE FDD: B1 (2100), B2 (1900), B3 (1800), B4 (AWS), B5 (850), B7 (2600), B8 (900), B12 (700), B13 (700), B17 (700), B20 (800), B28 (700), B66 (AWS-3)
TDD LTE: B38 (2600), B40 (2300), B41 (2500) |
| WLAN |
802.11 a/b/g/n/AC/ax 2.4 G+5 GHz, HE80, MIMO, 1024 QAM |
| BLUETOOTH |
Bluetooth® 5.0 |
| GPS SENSOR |
GPS, Glonass, Beidou, Galileo |
| USB |
USB 3.1 Gen. 1 |
| CONNECTIONS |
Wi-Fi Direct, NFC, ANT+ |
| SIM CARD |
1x Nano SIM (4FF) |
| SOFTWARE |
| OPERATING SYSTEM |
Android™ 12 |
| SAFETY |
Samsung KNOX 3.x |
| SMS/MMS |
yes |
| AMBIENT CONDITIONS |
| AMBIENT TEMPERATURE |
-20 … 55 °C (-4 … 131 °F) |
| MECHANICAL SPECIFICATIONS |
| DEGREE OF PROTECTION |
IP64 according to EN/IEC 60079-0 (ATEX/IECEx)
IP68* according to EN/IEC 60529 (industrial standard) and MIL-STD-810H |
| MASS |
610 g |
| DIMENSIONS |
H x W x D 126.8 mm x 213.8 mm x 9.9 mm |
| FURTHER APPROVALS |
MIL-STD-810H |
| GENERAL INFORMATION |
| NOTE |
* IP68 is based on test conditions for submersion in up to 1.5 meters of freshwater for up to 30 minutes. |
II 3G Ex ic IIC T5 Gc IP64
